Technical Parameters
Model:51.2V314AH
Rated Energe:16KWH
Cell Configuration:16S1P
Pack Over-voltage protection:58.4V
Pack over voltage Release:54V
Pack under voltage protection:42v
Pack Under-Voltage Release (V):48v
Cell Over-Voltage Protection:3.68v
Cell Over-Voltage Release:3.4v
Cell Under-Voltage Protection:2.5V
Cell Under-Voltage Release:2.9V
Nominal Charge/Discharge Current:140A
Max. Discharge Current :200A
Short-circuit Protection Current:400A±100A
Dimensions, D*W*H:688*300*800 mm
Weight:128kg
Operating Self-Consumption Current:≤60mA
Low power mode Current:≤100uA
Depth of Discharge :>80%
Cycle Life :≥8000 times (<0.5C,25℃ Cycle)
Charge Temperature:0~55℃
Discharge Temperature:-20~55
Storage Temperature:-20℃)~+45℃)（≤1 month）; 0~+35(≤1 year)
Communications:RS485/CAN/ RS232(Not used by default)
Parallel connection:16unit
Installation :Floor-mounted installation
